LR035761 LR057692 For Land Rover Range Rover sport LR4 LR068128 LR08reelander For Volvo WXLR006

Name: LR035761 LR057692 For Land Rover Range Rover sport LR4 LR068128 LR08reelander For Volvo WXLR006
Brand: GUANG ZHOU CFY C&U AUTOMOBILE AIR CONDITIONER CO.LTD
SKU: LR068128 LR086043 LR112585
Availability: InStock

Brand Name:	NBT
Model Number:	LR068128 LR086043 LR112585
MOQ:	1pc
Price:	Negotiation
Payment Terms:	L/C, T/T, MoneyGram, Western Union
Supply Ability:	10000pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

ISO9001

Brand Name:

NBT

Warranty:

12 Months

OE NO:

LR068128 LR086043 LR112585

Place Of Origi:

Guangdong, China

Size:

Standard Size

Model Number:

F-PACE (X761)

Car Model:

Air Compressor For Land Rover

Voltage:

12V

Condition:

100% New

Product Name:

A/C Compressor

Type:

Compress

Quality:

High-Quality

Packaging Details:

Wooden box packaging / carton packaging

Supply Ability:

10000pcs/month

Highlight:

LR068128

LR086043

LR112585

Product Description

Auto Parts LR035761 LR057692 Ac Compressor For Land Rover Range Rover sport LR4 LR068128 LR086043 LR112585

Product Details

Type	Air Conditioner Compressor
Condition	New
Place of Origin	Guangdong, China
OE NO.	LR068128 LR086043 LR112585
Size	OEM standard
Warranty	12 months
Place of Origin	China
Brand Name	NBT
Car Model	Air Compressor For Land Rover
Product name	A/C Compressor
Certification	ISO 9001
OEM	OEM Services Provided
Condition	100% Brand New
Quality	100% Professional Tested
Voltage	12V
Control Method	Automatic adjustment
Model Number	F-PACE (X761)
delivery time	3-15 Days

Our Service

We support ODM and OEM service

According to your special requests or drawing and sample

Steady product quality, strict quality control

Delivery promptly, good after-sale service

Our Company is a professional manufacturer of automotive air conditioning industry. We have a high degree of professional production

equipment. The factory mainly produces electromagnetic clutches, automotive air conditioning system parts, compressor assembly and so on. our

clutches have been exported to the United States, Middle East, Southeast Asia, Africa, etc.

About Compressors :

1)Rotary vane compressors consist of a rotor with three or four vanes and a carefully shaped

rotor housing. As the compressor shaft rotates, the vanes and housing form chambers.

The R134a is drawn through the suction port into these chambers, which become smaller as

the rotor turns. The discharge port is located at the point where the gas is fully compressed.

The vanes are sealed against the rotor housing by centrifugal force and lubricating oil. The

oil sump and oil pump are located on the discharge side, so that the high pressure forces oil

through the oil pump and then onto the base of the vanes keeping them sealed against the

rotor housing.

During idle an occasional vane noise from the compressor may be heard. This is due to the

time taken for lubricating oil to circulate through the A/C system.

2)Scroll type - Sanden

This compressor uses a unique design with two scrolls, one fixed and one is movable, both are inter-leaved.

The movable spiral is able to ORBIT or oscillate without actually fully rotating. The movable scroll is connected

to the input shaft via a concentric bearing.

As the movable spiral oscillates within the fixed spiral, a number of pockets are formed between the spiral. As

these pockets decrease in size the refrigerant is squeezed, the pressure increases and is discharged

through a reed valve at the discharge port in the rear section of the compressor.

3)Variable stroke - Harrison V5

The Delphi (Harrison) V5 compressor is a non-cycling variable displacement compressor.

The compressor varies displacement to control capacity to meet A/C system demand at all operating conditions. The compressor features a variable angle wobble plate in five (V5) cylinder axial piston design.

Displacement is controlled by a bellows actuated control valve located in the rear cylinder head. This control valve senses and responds to the system suction pressure or A/C system demand.

Through regulation of compressor crankcase pressure, the wobble plate angle, and therefore compressor displacement is variable.

In general, the compressor discharge pressure is much greater than the compressor crankcase. Which is greater than or equal to the compressor suction pressure.

At maximum displacement, compressor crankcase pressure is equal to the compressor suction pressure.

At reduced or minimum displacement, the compressor crankcase pressure is greater than the suction pressure

FAQ

Q1. How is quality ensured?

A: All our processes strictly adhere to ISO-9001 procedures. And we have a one year quality warranty B/L issue date.

If the product does not work property as described, and the problem is proven to beat our fault, we will provide exchange services for the same specific item.

Q2. Do you make customer' s auto AC parts?

A:Yes,you can send us samples and we can develop the new models especially for you.

Q3. What about delivery time?

A: lf we have stock of the item you need; we can send goods to you within 2 working days after deposit or 100% payment into our bank account. If we don' t have stock. The time to make each product is different generally, it takes 1 to 15working days.

Q4. How does to control your products?

A: 1.There is advanced equipment, professional and technical workers in the factory

2.Factory will have sample testing on quality before shipment

3.Our QC (QUALITY CONTROL) will check the quality of each product before shipment.

Q5. What about your packing?

A: Generally, we pack our goods in brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
